Kyosho Inferno GT2 Race Spec Corvette

Large-scale machine evolves with a power surge in performance!

Fully featured specifications can even take on high-speed circuit racing.

Kyosho’s popular INFERNO GT2 gets a racing spec upgrade! Big 1/8 scale matches a high-power engine with detailed scale body form to deliver awesome strength and style. Chassis dimensions deliver rock-solid running stability from the driving force of the easy to handle yet high-power KE25 engine that delivers more torque and faster maximum speeds than the former GT2. The previously optional shoe-type 2-speed transmission (IGW008) is now included as standard and realizes smoother gear changes and minimizes shift shock. A harder main chassis material combines with a resin chassis stiffener that responds with both strength and smoothness as required. The advanced 2.4GHz KT-201 R/C system features a blue backlit LCD that allows clear visibility and adjustment of each control setting. Other advanced features include a failsafe function that stops the car safely in the event of radio signal trouble and reliable ABS braking. High-torque KS-200 servos incorporating tough metal gears are equipped on both steering and throttle for precision control of the big chassis. Packaged as a complete Readyset, the INFERNO GT2 Race Spec can be ready for action fast. Feel the amazing power and performance of big scale R/C with the INFERNO GT2 Race Spec.                                                                                                                                                                                                                                                            Almost square dimensions of 310mm width and 360mm wheelbase deliver rock-solid running stability.                                                                                                                                                                                                               Optimal displacement of the KE25 engine generates plenty of powerful drive energy. Premium grade polished muffler and manifold are included as standard.                                                                                                                                                                                                                                                     Inferno MP-7.5’s superior suspension function has been optimized for on-road performance.                                                                                                                                                                                                                                   High grip tires combine with high strength wheels to deliver the edge in racing battle.                                                                                                                                                                                                                                             Includes the large capacity air cleaner. Maintains engine performance over long periods.                                                                                                                                                                                                                                               Front/rear independent disc brakes deliver reliable braking power. Thick brake discs minimize change in brake feeling from heat.                                                                                                                                                       Engine’s power band used to greater effect with the shoe-type 2-speed transmission using gear ratio 1st 15 : 46 and 2nd 18 : 43.

150cc fuel tank delivers about 10 minutes per tank without refueling.

                                                                                                                                       Kyosho’s unique 2.4GHz “Syncro KT-201/KR-200” transmitter and receiver incorporate additional functions and are designed for easy operation.



A Readyset is a fully assembled model that includes nearly everything you need to run. Body Color scheme is complete so only consumables like batteries and fuel are required so you can start operating the model without delay.

< ReadySet Contents >

  • Fully assembled chassis complete with 2channel 2-servo control and linkages installed.

  • Pre-cut and pre-painted body complete with decals applied

  • PERFEX KT-201 transmitter

  • Note) AA-sized alkaline batteries x 8 for transmitter/receiver, and fuel are sold separately.

Chassis Technical Data

Length

515mm

Width

310mm

Height

135mm

Wheelbase

360mm

Tread (F/R)

262mm/265mm

Tire(F/R)

F97mm ×40mm

Gear Ratio

1st 10.14:1, 2nd 7.90:1

Weight

3,650g (approx.)

Engine

KE25

R/C System

KT-201

Syncro KT-201 Set

Kyosho’s unique 2.4GHz “Syncro KT-201/KR-200” transmitter and receiver incorporate additional functions and are designed for easy operation. Simply switch the power ON and the system is ready to use straight away. The stylish form of the transmitter features a built-in antenna and an ergonomic design for comfortable switch positioning and a large, high visibility LCD display. The Syncro is also energy efficient and uses only four AA-size alkaline batteries. Its precision balance and lightweight are ideal for endurance racing and help maintain concentration without becoming fatigued and also make it easy to activate required functions and settings. From fun-running to the intensity of serious racing, the new generation Syncro 2.4GHz will deliver a greater appreciation of your R/C model’s performance.





F-16C Grey Super Scale 90mm with 12 Blade EDF Ducted Fan Jet RC Airplane PNP

Mission:
The F-16 Fighting Falcon is a compact, multi-role fighter aircraft. It is highly maneuverable and has proven itself in air-to-air combat and air-to-surface attack. It provides a relatively low-cost, high-performance weapon system for the United States and allied nations.                                                                             Features:
In an air combat role, the F-16’s maneuverability and combat radius (distance it can fly to enter air combat, stay, fight and return) exceed that of all potential threat fighter aircraft. It can locate targets in all weather conditions and detect low flying aircraft in radar ground clutter. In an air-to-surface role, the F-16 can fly more than 500 miles (860 kilometers), deliver its weapons with superior accuracy, defend itself against enemy aircraft, and return to its starting point. An all-weather capability allows it to accurately deliver ordnance during non-visual bombing conditions.

In designing the F-16, advanced aerospace science and proven reliable systems from other aircraft such as the F-15 and F-111 were selected. These were combined to simplify the airplane and reduce its size, purchase price, maintenance costs and weight. The light weight of the fuselage is achieved without reducing its strength. With a full load of internal fuel, the F-16 can withstand up to nine G’s — nine times the force of gravity — which exceeds the capability of other current fighter aircraft.                                                                The cockpit and its bubble canopy give the pilot unobstructed forward and upward vision, and greatly improved vision over the side and to the rear. The seat-back angle was expanded from the usual 13 degrees to 30 degrees, increasing pilot comfort and gravity force tolerance. The pilot has excellent flight control of the F-16 through its “fly-by-wire” system. Electrical wires relay commands, replacing the usual cables and linkage controls. For easy and accurate control of the aircraft during high G-force combat maneuvers, a side stick controller is used instead of the conventional center-mounted stick. Hand pressure on the side stick controller sends electrical signals to actuators of flight control surfaces such as ailerons and rudder.

Avionics systems include a highly accurate enhanced global positioning and inertial navigation systems, or EGI, in which computers provide steering information to the pilot. The plane has UHF and VHF radios plus an instrument landing system. It also has a warning system and modular countermeasure pods to be used against airborne or surface electronic threats. The fuselage has space for additional avionics systems.                             Background:
The F-16A, a single-seat model, first flew in December 1976. The first operational F-16A was delivered in January 1979 to the 388th Tactical Fighter Wing at Hill Air Force Base, Utah.

The F-16B, a two-seat model, has tandem cockpits that are about the same size as the one in the A model. Its bubble canopy extends to cover the second cockpit. To make room for the second cockpit, the forward fuselage fuel tank and avionics growth space were reduced. During training, the forward cockpit is used by a student pilot with an instructor pilot in the rear cockpit.

All F-16s delivered since November 1981 have built-in structural and wiring provisions and systems architecture that permit expansion of the multirole flexibility to perform precision strike, night attack and beyond-visual-range interception missions. This improvement program led to the F-16C and F-16D aircraft, which are the single- and two-place counterparts to the F-16A/B, and incorporate the latest cockpit control and display technology. All active units and many Air National Guard and Air Force Reserve units have converted to the F-16C/D.                                                                                                         The F-16 was built under an unusual agreement creating a consortium between the United States and four NATO countries: Belgium, Denmark, the Netherlands and Norway. These countries jointly produced with the United States an initial 348 F-16s for their air forces. Final airframe assembly lines were located in Belgium and the Netherlands. The consortium’s F-16s are assembled from components manufactured in all five countries. Belgium also provides final assembly of the F100 engine used in the European F-16s. Recently, Portugal joined the consortium. The long-term benefits of this program will be technology transfer among the nations producing the F-16, and a common-use aircraft for NATO nations. This program increases the supply and availability of repair parts in Europe and improves the F-16’s combat readiness.

U.S. Air Force F-16 multirole fighters were deployed to the Persian Gulf in 1991 in support of Operation Desert Storm, where more sorties were flown than with any other aircraft. These fighters were used to attack airfields, military production facilities, Scud missiles sites and a variety of other targets.

During Operation Allied Force, U.S. Air Force F-16 multirole fighters flew a variety of missions to include suppression of enemy air defense, offensive counter air, defensive counter air, close air support and forward air controller missions. Mission results were outstanding as these fighters destroyed radar sites, vehicles, tanks, MiGs and buildings.

Since Sept. 11, 2001, the F-16 has been a major component of the combat forces committed to the war on terrorism flying thousands of sorties in support of operations Noble Eagle (Homeland Defense), Enduring Freedom in Afghanistan and Iraqi Freedom.                                                                                                                                          General characteristics
Primary function: multirole fighter
Contractor: Lockheed Martin Corp.
Power plant: F-16C/D: one Pratt and Whitney F100-PW-200/220/229 or General Electric F110-GE-100/129
Thrust: F-16C/D, 27,000 pounds
Wingspan: 32 feet, 8 inches (9.8 meters)
Length: 49 feet, 5 inches (14.8 meters)
Height: 16 feet (4.8 meters)
Weight: 19,700 pounds without fuel (8,936 kilograms)
Maximum takeoff weight: 37,500 pounds (16,875 kilograms)
Fuel capacity: 7,000 pounds internal (3,175 kilograms); typical capacity, 12,000 pounds with two external tanks (5443 kilograms)
Payload: two 2,000-pound bombs, two AIM-9, two AIM-120 and two 2400-pound external fuel tanks
Speed: 1,500 mph (Mach 2 at altitude)
Range: more than 2,002 miles ferry range (1,740 nautical miles)
Ceiling: above 50,000 feet (15 kilometers)
Armament: one M-61A1 20mm multibarrel cannon with 500 rounds; external stations can carry up to six air-to-air missiles, conventional air-to-air and air-to-surface munitions and electronic countermeasure pods
Crew: F-16C, one; F-16D, one or two
Unit cost: F-16A/B , $14.6 million (fiscal 98 constant dollars); F-16C/D,$18.8 million (fiscal 98 constant dollars)
Initial operating capability: F-16A, January 1979; F-16C/D Block 25-32, 1981;  F-16C/D Block 40-42, 1989; and F-16C/D Block 50-52, 1994
Inventory: total force, F-16C/D, 1017

Product description

Features:
Large scale electronic ducted fan RC jet sporting an accurate 77th FS “Gamblers” livery
12 Blade factory balanced EDF with metal housing combined with 3748-1550KV brushless outrunner motor produces realistic jet turbine sound
Composite fan blades combined with metal EDF housing ensure AMA compliance
Hobbywing 130A with 8A UBEC
Electric retracts with scale, shock-absorbing struts and main operation,
Sequenced gear doors
Removeable wings, stabilators, vertical stabilizer, and nose cone for easy transport and compact storage
Machine screws and brass threaded inserts are used to attach the wings for a secure fit and longevity
Gap-less hinges on ailerons and rudder for scale appearance
Bright LED navigation lights
Pre-installed LED afterburner
Carbon fiber wing spars and reinforced body parts
Upgraded pushrod clevis and metal ball head connectors on elevators provide a robust connection between servo and control surface and eliminate “play”
Nylon hinges on all control surfaces                                                                                                                                      Spec:
Wingspan: 1023mm / 40.27in
Length: 1522mm / 59.92in
Flying Weight: 3550g / 125.22oz
Power System: 3748-1550kV Motor with 3150g thrust
ESC: 130A ESC, 8A UBEC, XT150 Connector
EDF: 90mm Metal Housing EDF with 12 Blade Fan
Servos: 9g*4, 17g *5
Landing Gear: CNC electric retracts with scale, shock-absorbing struts and main operation
Required Battery: 6S 22.2V 5000mAh 50C(Not Included)
Required Radio: Minimum 7 Channel(Not Included)
Ailerons: Yes
Elevator: Yes
Rudder: Yes
Flaps: Yes
Lights: Yes
Material: EPO Foam
Package Options:PNP(everything included except radio, receiver, battery and charger)

Credits: http://www.af.mil/About-Us/Fact-Sheets/Display/Article/104505/f-16-fighting-falcon/
http://motionrc.com       RC Canada RC USA  http://

GAUI X7 Basic Helicopter Kit G-217001

  • Succinctly & stylishly designed FBL main rotor head and swash plate which produces quicker response and superior control precision.

  • I-shape structure and narrow designed CF main frame results in a high rigidity for 3D maneuvers.

  • Equipped with high efficiency heavy-duty torque tube driven tail, which brings excellent performance either in high or low head speed.

  • High modulus drive gears/bevel gears can also be compatible for upgrading to 800 class.

  • Highest spec CNC 6065 & 7075 aluminium parts, with highest load tolerance and precision for superior 3D performance.                                                                                                                                                                                       ♦Succinctly &amp, stylishly designed FBL main rotor head and swash plate which produces quicker response and superior control precision.                                                                                       ♦I-shape structure and narrow designed CF main frame results in a high rigidity for 3D manoeuvres.                                                                                                                                                                               ♦Equipped with high efficiency heavy-duty torque tube driven tail, which brings excellent performance either in high or low head speed.                                                                                           ♦Stylish painted FRP canopy.

    Content:

    X7 Basic Kit x 1 set                                                                                                                                                                                                 X7 Standard Canopy Protective Cover x 1 pc

    Specifications:

    Length: 1340mm
    Height: 370mm
    Main rotor diameter: 1610mm
    Tail rotor diameter: 290mm
    Motor drive gear: 10T (Ø 6mm)
    Main drive gear: 100T
    Drive gear ratio: 10:1:4.71
    Weight (kit): 2300g
    Powered by: (v) Battery: type (LiPo) qty. (2) 6S*2, 4200~5500mAh.

    Optional Accessory:

    Standard size CCPM servos * 3pcs (>15kg torque)
    Standard size tail servo * 1pc
    3-Axis Gyro * 1pc
    450~500 KV Blushless motor * 1pc
    (Motor shaft length ~46mm, Ø6mm)
    12S 120~160A ESC * 1pc
    690~710mm main blades * 1 pair
    95~105mm tail blades * 1 pair
    Battery :6S1P (22.2V/4200mAh ~5500 mAh) x 2pcs                                                  http://

Scorpion XXL Nitro RC Car

Looks BAD, runs good! Easy to run, tough on the competition!

With a chassis and power source combination that delivers a sharp control feel, the concept of large-scale off-roaders has been altered forever with the introduction of the Scorpion XXL VE 2WD racing buggy. This high-performance racing weapon dominates land and air with the power to charge over big jumps through off-road racing circuits and rough terrain. Now a powerful GP model joins the Scorpion XXL series that stormed across the world with its sharp control feel around the suspension and chassis layout with centralized weight featuring a midship mounted XXL engine fitted with pull starter.                                                                                                                                   The unique design effectively maintains rear traction while reducing the under steer characteristic of 2WD vehicles. The full benefits of the engine power source are captured while the suspension is even more flexible than the VE model to deliver a unique finish despite the number of components shared across both chassis platforms. A waterproof RC system including the KS203 servo incorporating metal gears delivers a sharp response with (4 x AA) alkaline batteries through the KR200 receiver with failsafe function and the 2.4GHz KT201 transmitter featuring an LCD display for precision setting adjustments. With the XXL engine mentioned above included, high torque delivers dynamic big scale car performance while the long manifold and large silencer generate additional power output. A large 210cc fuel tank delivers run times of more than 12 minutes while the fuel tank cap is styled as an air intake to add even more character to the model. The easy-start engine is also simple to switch off with the newly developed cutoff switch. These enhancements are designed to make owning and running a GP engine model simpler and easier than ever before. The throbbing sound of engine power and exhaust build performance expectations that this big scale buggy can meet and exceed as you experience off-road racing like never before!                                                                                                                                                                             Large 3D shaped air intake on the side of the body channels a fresh air stream into the chassis for extra engine cooling. ※Black is a color image overseas.                                                                                                                                                                    Features cutoff switch that stops engine easily. Combines with easy-start engine to make it easier for first-time users of GP models.                                                                                                                                                                                     Features a 3-piece clutch that delivers reliable performance, even under the heavy loads of a big scale model and the powerful torque of the engine.                Large slipper clutch installed. Protects drive train from the excessive shock. Minimizes wheel spin.                                                                                                     Front knuckle with small scrub setting eliminates the slow steering feel typical of large-scale models.                                                                                                   Features air-intake styled fuel cap.                                                                                      Realistic rear exhaust enhances power and keeps your whip CLEAN.                      The 2.4 GHz KT201 transmitter provides precision control and displays the settings for each function on the LCD screen such as EPA and ABS brakes. The KR200 receiver features a fail-safe setting, and a high torque KS203 servo with an aluminum case and metal gears is also included in the factory-assembled Scorpion XXL VE. Only batteries for the transmitter and 2 to 4S LiPo batteries are required to experience the powerful performance and pure excitement of big-scale off-road buggy racing.                                                          High response & torque waterproof servo delivers next-level performance for a factory-built machine.

A Readyset is a fully assembled model that includes nearly everything you need to run. Body Color scheme is complete so only consumables like batteries and fuel are required so you can start operating the model without delay.

< ReadySet Contents >

  • Fully assembled chassis complete with 2channel 2-servo control and linkages installed.

  • Pre-cut and pre-painted body complete with decals applied

  • PERFEX KT-201 transmitter

< Required for Operation >

  • AA-sized alkaline batteries x 8 for transmitter/receiver

  • Engine starting tools

  • Fuel

Chassis Technical Data

Length

630mm

Width

402mm

Height

244mm

Wheelbase

452mm

Tread (F/R)

353 / 331mm

Tire(F/R)

Φ130×43mm / Φ140×71mm

Gear Ratio

16.0:1

Weight

4000g (with body)

Engine

XXL Engine (.28 class)

         http://

Waco YMF-5D Radio Controlled Glow or Gasoline Powered .91-1.20 Scale ARF Biplane

The number of sleek, fast aircraft boomed during the Golden Age of Aviation, but none could compare with the Waco. Today, the Waco YMF-5D offers the same timeless good looks and the benefits of modern technology. Great Planes’ replica recreates its smooth, flowing lines and classic style in sport-scale detail, painted fiberglass and rich MonoKote® film.                              The Waco offered more than good looks. It was used as a 3-seat trainer as well as a mail carrier. Parts to create both versions are included and simple to install.                                                                                                                                                                                                                                    Engine options are wide open. The O.S® FS-120S-E offers the best in 4-stroke power and scale sound. The low-cost DLE-30 provides true gas economy and the ease of electronic ignition.                                                                  Installing the replica radial takes a few minutes, but the cowl blister detail is factory-applied and ready for admiration. What’s more, there are no screw holes to distract from the cowl’s good looks. A hidden ring secures it “invisibly!”                                                                                                                                    The main gear is a scale version of the ’34 original. Other painted fiberglass parts include wheel pants, struts and cabanes and fairings to ensure smooth transitions from the fuselage to the wings and landing gear.                                   Tubes ensure that the horizontal stabilizer is perfectly aligned, as well as faster and simpler to install.                                                                                                                                                                                            A slow flyby is just right for showing off the Waco’s impressive size, stable handling and outstanding looks. Each aileron has a dedicated servo, ensuring swift, dependable response, shorter linkages and easier installation and adjustment.                                                                                                  The Waco’s smooth lines and signature trim scheme were instantly recognizable even at the smallest country airfields. A scratchbuilt or kit-built Waco could take months to complete, but you can have this sport-scale ARF assembled and in the air in just a few days.

Features:

  • Tubes for the horizontal stabilizer simplify alignment and installation, reducing assembly time.

  • Painted fiberglass parts – including the cowl, struts, cabanes, wheel pants and fairings – ensure seamless looks and fast installation.

  • A hidden ring secures the cowl without screw holes, preserving scale looks.

  • The Waco was used as a 2-seat trainer as well as a mail carrier. Parts to create both versions are included and simple to install.

  • Versatile – can be operated as a gas or glow power aircraft.

Requirements:

  • Radio (minimum of 4 channels)

  • Servos (7)

  • 2-stroke .91, 4-stroke 1.20 Glow or 25-30 cc Gas Engine

  • Propeller, building, and field equipment

Specifications:

  • Wing Span: 72 inch (1830 millimeters)

  • Wing Area: 1384 square inches (89.2 square decimeters)

  • Weight: 12.75 – 13.75 pounds (5.78 – 6.23 kilograms)

  • Wing Loading: 21 – 21 ounces/square foot (64 – 70grams/square decimeter)

  • Length: 56.5 inches (1435 millimeters)

  • Center of Gravity (CG): 5.25 inches (133 millimeters) back from the leading edge of the top wing

  • Control Throws – Low Rate High Rate

  • Elevator Up and Down, 11/16 inches (17 millimeters) 8° 1-1/4 inches (32 millimeters) 14°

  • Rudder Right and Left, 1-3/4 inches (44 millimeters) 17° 2-1/4 inches (57 millimeters) 22°

  • Ailerons Up and Down, 11/16 inches (17 millimeters) 14° 7/8 inches (22 millimeters) 18°

From the Manufacturer

This is the radio controlled, glow or gasoline powered, almost ready to fly Waco YMF-5D Biplane from Great Planes. Includes parts to build a two-seat trainer or a single pilot mail carrier. IMAA-Legal 72 Wingspan.                               Red Line Remote Control

ALIGN T-REX 550L Dominator Super Combo RH55E12X Microbeast PLUS

The internationally popular T-Rex 550 has long been a trend setting helicopter, every enthusiasts probably has owned at least one. It is the ideal model for beginners as well as experts practicing advanced maneuvers. Now the T-Rex 550 evolution continues, as Align drops another shocker into the market; with even more innovative designed incorporated, the brand new T-Rex 550L Dominator.                                                                                                                                                                                                             With a size that fall in-between large and small models, T-REX 550 features stability and agility which is the most popular model for pilots in all classes to practice. Now T-REX 550L Dominator inherit with all outstanding design concepts and much superior power supply that will guaranteed jaw dropping performance.                                                                                                                                                                                                                                        T-REX 550L firstly utilizes composite material integration technology on carbon side frame plates, also adding battery mounting rails and top mounted motor base design make assembly easy and protectable. Designed with direct servo CCPM control, and a single piece main bearing block with integrated servo mounts; plus equipped with the low CG DFC rotor head, exhibits exhilarating 3D performance and unimaginable flight speed. High quality new tail gearbox design, combined with new dual point mounted tail pitch control assembly to minimize slops and increase rudder control precision.                                                                                                                                                                                                                                    T-REX 550L Dominator equipped with 730MX 850KV motor with unique DOMINATOR painting scheme and extremely efficient and powerful output; brand new high voltage brushless BL815H/BL855H servos features with high torque and super efficiency reaction and higher precision; also keep extremely low temperature after flight not only can extend the service life but also be the favorite ones for all our factory pilots.

The most important upgrade should be Microbeast PLUS flybarless system, all the up-to-date devices are all included, must be your best choice to try on, just don’t miss it and get a T-REX 550L Dominator right now.

Specification:
Length: 1070mm
Height: 337mm
Width: 210mm
Main Blade Lenght: 550mm
Main Rotor Diameter: 1248mm
Tail Rotor Diameter: 254mm
Motor Drive Gear: 16T
Main Drive Gear: 112T
Autorotation Tail Drive Gear: 131T
Tail Drive Gear: 34T
Drive Gear Ratio: 1:7:3.85
Weight(w/o power system): 2790g


Accessories:

T-REX 550L DOMINATOR Kits Set x 1 set
550 Carbon Fiber Blades x 1 set
90mm Carbon Fiber Tail Blade x 1 set
730MX Brushless Motor(850KV) x 1
BL815H High Voltage Brushless servo x 3
BL855H High Voltage Brushless servo x 1
Castle Talon 90 Brushless ESC x 1
Microbeast PLUS Flybarless System X1 set


Radio transmitter and electronic equipment required for assembly:

1.Transmitter(7-channel or more,helicopter system)
2.Receiver(6-channel or more)
3.Pitch gauge or Digital Pitch Gauge
4.6S Li-Po 1100~1400mAh battery x 1

Traxxas 5707 Spartan VXL with Castle System and 2.4GHz Radio

It’s the kind of boat you would expect from Traxxas: Extreme Velineon® brushless power, ballistic speed, and a huge waterfall of roost that rains down long after the boat speeds by. The howling fury of 50+ mph across the water on optional 6S LiPo power will make even the most insatiable, power-hungry enthusiasts jump up and take notice. Simply put, Spartan is your boat! Everything about it means business: the super-rigid, 36-inch deep-V hull; smooth, cable-drive efficiency; innovative water cooling system; and precision aluminum and stainless steel drive controls.                                               The clean, modern hull design is built up in layers for maximum rigidity where it matters most, the transom and ride pad. The integrated battery trays securely hold a variety of battery configurations—from the included 7-cell Power Cell NiMH packs to 3S LiPos. Ride trim is easily adjusted by positioning the packs fore and aft using the convenient hook and loop straps that secure the batteries.                                                                                                                                                                                                                The optimized rudder configuration carves amazing full-throttle turns. A high-output 2.4GHz radio system, along with water-cooled and waterproof electronics, keep Spartan going for the trouble-free, all-day running you count on from Traxxas. No detail was overlooked on our mission to engineer a boat that offers the power, speed, convenience, and fun that Traxxas’ award-winning cars and trucks are known for. Prepare yourself for the ultimate R/C boating power trip, only from Traxxas.

100% Ready-To-Race®

Spartan is fully assembled with a TQi™ 2.4GHz radio system, Velineon brushless power system, applied graphics, and detailed instructions. Two Traxxas Power Cell 7-cell NiMH batteries are also included. Designed specifically for the high-power needs of the Velineon brushless system, the potent Power Cell packs feature heavy-duty construction, 12-gauge wires and patented Traxxas’ High-Current Connectors for efficient power transfer, run after run. Traxxas backs the Spartan and all of our products with industry-leading support that is second to none. A staff of skilled representatives is on-hand to answer your questions via phone, website, or e-mail. Unmatched parts support allows Spartan to be serviced with parts and support from thousands of hobby dealers worldwide. Your investment is also protected by the Traxxas Lifetime Electronics Warranty. Traxxas goes the extra mile to ensure that your R/C experience is easy and fun—and fast!

The World’s Most Advanced Ready-To-Race® Radio System

Spartan is equipped with the world’s most advanced Ready-To-Race® radio system. The Traxxas® TQi™ arrives with a full complement of tuning features and offers the unbeatable convenience of “no channels, no crystals” 2.4GHz technology—but that’s just the beginning. Automatic model recognition instantly recalls your settings for up to 30 Traxxas Link-enabled models. Just switch on and drive, no naming or “model memory” settings required. Power up the transmitter and the model you want to drive, and the settings for that model are dialed in immediately! The new TQi 2.4GHz transmitter is fully adjustable: steering and throttle end points can be set precisely, and the Multi-Function knob can be programmed to control Steering Sensitivity (Expo), Throttle Sensitivity (Expo), Steering Percentage (Dual Rate), Braking Percentage (Dual Rate), or Throttle Trim. TQi’s ergonomic case design provides all-day driving comfort, and the unique internal antenna contributes to its sleek, modern look.

TQi Docking Base Compatible

The TQi’s most important feature may already be in your pocket. The TQi can be equipped with an optional Docking Base (#6510) that turns your iPhone® or iPod touch® (sold separately) into a powerful tuning tool for your Traxxas model. The full-color display combines with the free Traxxas Link™ App (on the App Store) to deliver an intuitive, high-definition, full-color graphical user interface that unlocks the mysteries of optimizing your radio system for ultimate vehicle control. Traxxas Link also opens the door to telemetry capability when you add optional sensors to your model. Click on one of the following links to learn more about the ground-breaking

QUICK FEATURES ON SPARTAN (#5707)

  • 30+mph out of the box, 50+mph on 6S LiPo!

  • 36″ deep-V hull for stable high-speed performance

  • Water-cooled, waterproof VXL-6s Marine speed control

  • 6S LiPo compatible with built-in Low-Voltage Detection

  • Traxxas High-Current Connectors (patented)

  • Velineon 540XL high-output brushless motor with highflow water-cooling jacket

  • Quick-release Power Module integrates power system, waterproof electronics, and stuffing tube

  • Adjustable battery trays with hook-and-loop straps

  • Blue-anodized aluminum rudder support, rudder, and drive strut

  • Stainless steel turn fins, trim tabs, and hardware

  • TQi 2.4GHz radio system

  • Includes two 7-cell Power Cell battery packs

  • Waterproof high-torque steering servo

  • Sleek design with factory-applied graphics

  • Ready-To-Race®

  • Traxxas factory support

  MODEL 5707: Fully assembled, Ready-To-Race®, TQi™ 2.4GHz radio system,
Velineon® 540XL Brushless Motor, VXL-6s Marine ESC and factory-applied graphics.                                                                                                                                           http://



Walkera Voyager 4 The Flying Telescope RTF4 4K HD / Gimbal / 16 Times Optical Zoom / Real Time HD Image

Real-time HD image transmission 4K HD video recording

Adopting the 5.8Ghz HD digital image transmission technology, characterizing as faster
transferring response, lower latency and stronger anti-interference ability



                                                                                                                                                     3-Axis brushless gimbal

Advanced shock absorber technology to ensure a stable shooting image quality.

An advanced shock absorbability gimbal technology which greatly reduced vibration and
movement during flight , enabling the camera to capture stabilized and fluid footage even after

Pitch

90°~+45°

Yaw

150°

Ultra light material

VOYAGER4 aircraft adopts ultra-light carbon fiber material,
substantially reducing aircraft weight as well as improving operational efficiency.

Retractable landing gear

With application of retractable landing gear ,enabling a cool profile and Unobstructed 360 degree shooting during flight.





Spec

Aircraft

Main Rotor Dia.:

382mm

Overall (L x W x H):

465 x 465 x 352mm

Weight:

3250g(Battery included)

Remote Controller:

DEVO F8W

Main Controller:

FCS-V4

Receiver:

DEVO-RX718

Brushless Motor:

WK-WS-42-002A

Brushless ESC:

Voyager 4 (R/B)

Battery:

22.2V 4500mAh 10C(6S) LiPo

Flight Time:

About 20mins

Working Temperature:

-10℃~ +40℃

Gimbal

Control accuracy:

Static: ±0.008°; Motion: ±0.08°; Shake-proof: ±0.008°

Control range:

Pitch rotation -90°~ +45°; Horizontal ±150°

Camera

Sensor:

1/2.3 SONY IMX117 CMOS

ISO Range:

100-3200(Video) / 100-1600(Image)

Video Resolution:

4K 30fps

Photo Resolution:

4608 x 3456

Focal Length:

6.7-134.5mm

Zoom Ratio:

18x optical zoom

Zoom Speed:

About 2.0s

Horizontal View:

59.8°- 3.0°(Wide Angle-Telescopic)

Close-shot Distance:

10 – 1500mm(Wide Angle-Telescopic)

Video Storage Maximum:

32Kbps – 16Mbps

Compress Standard:

H.264 / H.265

Files Format:

JPG/MP4

Support Micro-SD:

SD/SDHC Card(MAX128G)

Remote Controller

Overall (L x W x H):

165 x 174 x 62mm

Working frequency:

2.4G

Signal range:

About 1.5KM (open without shelter, no electromagnetic interference)

Built-in battery:

7.4V 3000mAh Li-po 2S







5 CH BlitzRCWorks VTOL V-22 Osprey RC Warbird Airplane

  Boeing is apparently working on a large passenger aircraft with vertical takeoff and landing features. The company received a patent for a tilt-rotor design that has room for at least 100 passengers, according to a Business Insider report Thursday. The VTOL plane has potential for both civilian and military use, according to the report. It seems to be inspired in part by the famous two-engine V-22 Osprey, which Boeing and Bell Helicopters developed for the U.S. military in the 1980s, the first of its kind designed for use by the Marines and Air Force. The patent for the unnamed aircraft includes potential uses for commercial flights, military missions or personal transport, according to the report. Its design includes four engines mounted on two fixed wings along with two large rotors attached on the tips for vertical takeoffs and landings.

The company hasn’t revealed details of its intentions for the VTOL design, but a civilian passenger plane with such capabilities will likely raise speculation about the potential for off-airport commercial transportation. “Boeing files tons of patents so this might not even come to fruition,” a Boeing spokesman told Business Insider. “I’m not saying it won’t.” The patented design also calls for lower wings on the airframe compared to the V-22 to allow for passenger exits as well as simpler maintenance, a Seattle Times report notes.

                                                                                                                                                       Do you know what VTOL means? Aside from vertical takeoff and landing, it means taking off and landing can be done in a multitude of different terrains. No runway necessary. This model was in the making for about 3 years, with countless hours of development and testing. There were a lot of hurdles in the way, but it’s finally here.                                                                               A market-first, and ground-breaking scale V-22 Osprey with full VTOL and forward flight capabilities. This beauty is built with a high-precision stabilization board, quality electronics, and of course, EPO foam. With its 3-point propulsion system, it manages to fly with unrivaled stability. Plus, the transition to forward flight seamlessly blends with the overall flying experience, making it easier on the pilot.                                                                           Currently there’s nothing like it in the scale and performance department, making this a one of a kind model. Did we mention, no runway necessary? Take it for a spin today!

Feature:
  • 5 operable channels (aileron, elevator, throttle, rudder and forward flight actuation)

  • Professional high-precision stabilization board

  • 3-point propulsion system for stability

  • Simple and easy to assemble

  • Built with high-grade EPO foam

  • Reliable dual 17g metal-gear servo system for forward flight actuation

  • Detachable main wings for ease of transportation

  • Spacious battery compartment for a variety of battery options

  • Scale appearance

  • High-performance propulsion system

  • Stable forward flight transition

Credits: https://www.avweb.com/  By Elaine Kauh | October 27, 2016     http://

AquaCraft Models Atlantic II Electric Powered 2.4GHz Radio Controlled Ready-to-Run Harbor Tugboat

Harbor Workhorse

We all feel the ocean’s pull. Soothe that yearning for the smell of salt spray and cry of gulls with the AquaCraft Atlantic II Harbor Tug. This exceptional watercraft is thoroughly detailed and arrives outfitted for instant outings. Drop in the LiPo battery of your choice and get out on the water immediately with a fully-trimmed red on black hull, 2.4GHz radio, pre-installed motor, working LED lights, and tons of scale detail in every inch. With runtimes of up to an hour with recommended batteries, the Atlantic II is the perfect way to spend an afternoon down by the lake.                                                                                                                                                                Cabin, nav, spot and mast lights add even more scale detail to this exceptional model.                                                                                                                                                                                                       A protective rubber cap on the bow and rubber tires lining both sides of the boat enhance scale realism and cushion minor impacts.                                                                                                                             Real-life details — including fire extinguishers, life preservers, ladders, portholes and more — are factory-painted and installed for added authenticity.                                                                                                                                                                                                                   The multi-level cabin doubles as a hatch that provides fast, easy access to all onboard electronics. Adding the recommended 11.1V LiPo battery gives the Atlantic II the capacity it needs for up to a full hour of easy sailing.                                                                                                       A large rudder and a 3-bladed brass propeller deliver smooth turns on command.

Tactic Logo

TTX491 4-Channel 2.4GHz Radio

Simple, straightforward and affordable, the TTX491 offers the ease of 2-stick control and two auxiliary channels for added functions. Servo reversing switches speed installation; digital trims let you customize performance and feel to your tastes. It comes with a 6-channel TR625 receiver. It features a push-button that creates an instant, unbreakable link between itself and your transmitter and prevents it from recognizing any transmitter except yours. Twin coaxial antenna ensure excellent signal clarity, even at the outer limits of the TR625’s range.

SLT Protocol Logo

Dependability-protected by the SLT Protocol.

The Atlantic II Tugboat includes:
